Low loader neck
Which type of neck best suits your operations?
Ask us
your question!
Which low loader necks are there?
Our low loaders are available with different types of necks, depending on the type of low loader and your load, you can choose the neck that best suits your operations. With all our necks, all functions can be controlled by remote control in addition to the standard control levers. Read more about our necks below.
Two beam neck (for 2- and 3-axle low loader)
Agri neck with pass-through for a drawbar
Chalet neck
Heavy duty neck (from 4-axle PL low loaders and for dolly low loaders)
Neck with fixed 1-axle dolly
Two beam neck (for 2- and 3-axle low loader)
Our hydraulically movable two beam neck with a maximum fifth wheel load of 18 t can be easily linked to a two beam bed (outer beam). The detachable neck makes loading quick and easy. By using the two beam principle, the rear swing radius is kept to a minimum, which benefits the load floor length. This is ideal for transporting long loads such as boats and silos. In addition, the neck is equipped with a flat deck and certified lashing rings, allowing loading on the neck. To allow the driver to step onto the neck safely, an aluminium cover plate is fitted between the neck beams.
Agri neck with pass-through for a drawbar
Our agri neck is a hydraulically movable two beam neck with a maximum fifth wheel load of 18 t. This neck can be easily linked to a central girder and is detachable, making the loading of tractors, seeders, harvesters or other machines quick and easy. With the two beam principle, there is a free space of 510 mm between the two neck beams, creating space for inserting the drawbar of an agricultural trailer or machine and eliminating the need for additional extension. This allows you to drive with the shortest possible overall length. The neck has a flat section and certified lashing rings, allowing loading on the neck.
Chalet neck
The chalet neck is a hydraulically adjustable two beam neck with a central beam and has a maximum fifth wheel load of 23 t. This neck is easily detachable for loading/unloading and is equipped with two hydraulic cylinders, allowing you to safely align the neck when detaching. By combining this neck with the chalet bed, equipped with folding ramps, you create the perfect solution for transporting chalets, tiny houses and other mobile housing. The neck is completely flat and has certified lashing eyes that allow you to load on the neck.
Heavy neck (from 4-axle PL low loaders and with dolly low loaders)
The heavy duty neck is a central beam neck that is hydraulically adjustable with a maximum fifth wheel load of 35 t. You can choose to link this neck with a two beam bed (outer beam) or a central beam bed. The neck is easily detachable and is equipped with two hydraulic cylinders, allowing you to safely support the neck when detaching. The neck has a flat deck and certified lashing rings, allowing loading on the neck. If this neck is used in a dolly low loader combination, the neck also has compensation between the neck and the dolly. As standard, the neck has a 3.5" kingpin.
Neck with fixed 1-axle dolly
This hydraulic neck with integrated 1-axle dolly has a maximum allowable fifth wheel load of 25 t and is applied to our 1 + 3, 1 + 4 and 1 + 5 axle dolly low loader combinations. This dolly is an additional fixed axle between the gooseneck and provides better weight distribution of the load. You can choose to link this neck with a dolly to a two beam bed (outer girder) or a central beam bed. The neck has a section and certified lashing rings, allowing loading on the neck. As standard, the neck has a 3.5" kingpin.
We are keen to help you make the right choice. Contact one of our advisers for solid advice and a no-obligation quotation.
