Looking for a 10-axle pendle axle semi?
This 10-axle pendle axle semi low loader is specially designed for heavy loads. This multi-purpose trailer can extend twice.10-axle double extendable pendle axle semi low loader PL2
A semi low loader for loads of 100+ tonnes and an enormous length? Our double-extendable 10-axle pendle axle semi low loader is then the perfect trailer for you. These three axles steer with the truck, making the 10-axle pendular semi low loader very manoeuvrable. The trailer is double-extendable to a maximum length of 40 metres.
Thanks to our latest production technologies, we know exactly where to reinforce the pendle axle semi low loaders and where we can make the trailers lighter. As a result, our pendle axle semi low loaders are lighter and have a lower ride height, allowing you to transport more cargo. Curious about what this trailer can do for you?
General
specifications
- 2x extendable
- Pendular axles (PL2)
- 245/70 R17.5 tyres
- Movable detachable neck
- Load capacity app. 115 t
Technical
specifications
- Fifth wheel load 30 t
- Bogie load 120 t
- Tare weight ca.36.5 t
- Platform height 870 mm
- Extension 18,000 mm
- Total extended lenght 40,435 mm
