4-axle self-tracking
construction semi low loader

Double wheel well and crane arm recess

Looking for a 4-axle construction semi?

This semi low loader makes transporting tracked and wheeled vehicles up to 50 tons much easier. Thanks to the double wheel wells and crane arm recess, you can reduce the transport height.

Ask us
your question!

Determine
your target price

General
specifications

  • 1x extendable
  • Airsuspension selftracking
  • 245/70 R17.5 tyres
  • Fixed neck
  • Load capacity app. 45 t
  • Double wheel well - crane arm recess

Technical
specifications

  • Fifth wheel load 18 t
  • Bogie load 40 t
  • Tare weight ca.11.6 t
  • Platform height 870 mm
  • Extension 2,000 mm
  • Total extended lenght 13,850 mm
Specification sheet

Related
products

4-axle construction semi low loader with ramps

This 4-axle self tracking construction semi low loader is equipped with double wheel wells, a crane arm recess and ramps. By extending the trailer, the front wheel well can be made larger. With this you can transport almost all types of construction machines.

4-axle plant semi low loader non-extendable

This 4-axle self tracking plant semi low loader is non-extendable and very strong. Thanks to the ramps, construction plant can be loaded safely and easily.

4-axle construction semi low loader

This 4-axle self tracking construction semi low loader is equipped with double wheel wells and a crane arm recess. By extending the trailer, the front wheel well can be made larger. With this you can transport almost all types of construction machines.

Innovations
and techniques

Paint system

The anti-corrosion protection of a trailer is essential, you cannot simply do it 'again', it has to be done right first time!

Wheel wells

A wheel well is a recess in the loading floor or a lowering of the loading floor. Because the tyres of vehicles are lowered, the transport height can easily be reduced.

Crane arm recess

A crane arm recess is a recess where the crane arm can easily be placed during the transport of a machine to reduce height.
